Cleaning workpieces carefully:

Our research and development has set the task of constructing systems that carefully remove manufacturing residues, chips/swarfs, grease and oils from your metal workpieces. Even throughout the construction phase, our focus was on thorough cleaning of hard-to-reach areas such as deep joints and edges. Our innovative 360-degree swivel system, the 2-stage cleaning system and the well thought-out positioning system, as well as the recycling system for the cleaning water are the result of our research and development. We also offer a tailor-made solution for your individual clamping system.

Pure

Photo By: John Doe
Button

City skyline

Photo By: John Doe

Dryer Photo Needed

Photo by: John Doe
Button

Series according to your needs:

As a series product, we offer our component cleaning machines in two versions: the standard model and the heavy model. We also focus on your individual needs here and adapt our series systems to clamping systems. When selecting the right cleaning solution, we focus on your processes.

model Standard Heavy
item number I-100-006-160 I-100-005-900
External dimensions (WxDxH) 1200x1400x2200 1600x1800x2200
Product area (WxDxH) 420x500x500 700x700x700
payload 250 kg 450 kg
rinse temperature max 40°C max 40°C
Tank volume 225 liters 450 liters

Questions and Answers

  • For whom are the systems useful?

    If you work with metal and your parts are milled, ground, turned or eroded, then you've come to the right place.

  • What can be cleaned?

    Workpieces of metal.

  • How does the 3-stage filter system work?

    3 filter stages are:

    1. coarse chips are removed
    2. fine particles such as dust are sorted out
    3. smallest particles (80my) are screened out by pump filter

  • Which media is used for cleaning?

    The rinsing procedures are based on cleaning with water and water-based degreasers.


    Surfaces are reliably cleaned from contaminants and oils (Drawing, punching, printing, cooling, lubricating oils).


    We tailor the solvents specifically to your processes for optimal cleaning results as well.

  • Where do we deliver?

    We deliver to customers worldwide.
